BJ-7000FT Fully Automactic Single Head Twisting, Crimping And Tinning Machine

bojin — Tue, 27 Sep 2016 06:22:02 +0000

Operation Video

Fully automactic Single head wire cutting, stripping, twisting, crimping and tinning machine BJ-7000FT
1. Automatic Cable Wire Cut Strip Twist Tinning Crimping & Soldering Machine
2.Automatic electric wire cutting stripping tinning pro cessing machine, both ends tin machine
3.Automatic electric wire cutting stripping tinning processing machine
4. Twisting wire tinning machine automation
5. Fully automatic terminal crimping machine
6. Automatic wire stripping, twisting and crimping machine

Description: five functions of wire separation, stripping, twisting, soldering and cutting in one and completed once for all

Machine features:

1, ultra-compact design, small footprint, computer touch-screen Chinese menu operation, easy to use;
2, The replacement process and the material very rapidly, high efficiency, high precision, speed, easy maintenance;
3, The machine uses servo control: 5 sets of servo (Delta servo Mitsubishi servo);
4, Pneumatic components: electromagnetic raft + cylinder (SMC), air pressure detecting SMC;
5, Screw rails: TPI / THK;
6, Color touch screen: Step Section (Taiwan);
7, The entire computer numerical control debugging: blade size, cutting wire length, strip length, twisting strength speed, flux dip depth, the depth of wetting, are to achieve digital touch screen operation;

* Dimesions:1200*1200*720
* Weight:500kg
* Display:LCD display English language touch screen
* Power:AC220/50Hz
* Fuction:Wire cutting, stripping a single-ended, double-ended stripping, single-head crimping, twisting single-ended line, single-ended tinning
* Wire size:AWG32#-AWG16#
* Speed:5500/h
* Cutting length:Max length 450mm
* Stripping length:0.1mm-10mm
* Tinning length:1mm-10mm (Changable)
* Twisting length:2mm-10mm (Changable)
* Available wire:Electronic wire, high temperature wire, etc.
* Twisting way:Digital Operation (motor drive mode)
* Detective function:Lack of wire, wire tie, pressure checking
* Air pressure:More than 6kg

BJ-7000FT Fully Automactic Single Head Twisting, Crimping And Tinning Machine

Payment & Delivery

* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.

We Provide

* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.

Service

* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine

bojin — Tue, 27 Sep 2016 05:52:17 +0000

Operation Video

Fully automactic Single head wire cutting, stripping, twisting, tinning machine BJ-2000FT
1.Automaitc electric wire cutting, stripping and tinnning processing machine, both end tin machine
2.Automatic electric wire cutting stripping tinning processing machine

Machine features:

1, ultra-compact design, small footprint, computer touch-screen Chinese menu operation, easy to use;
2, The replacement process and the material very rapidly, high efficiency, high precision, speed, easy maintenance;
3, The machine uses servo control: 5 sets of servo (Delta servo Mitsubishi servo);
4, Pneumatic components: electromagnetic raft + cylinder (SMC), air pressure detecting SMC;
5, Screw rails: TPI / THK;
6, Color touch screen: Step Section (Taiwan);
7, The entire computer numerical control debugging: blade size, cutting wire length, strip length, twisting strength speed,
flux dip depth, the depth of wetting, are to achieve digital touch screen operation;

* Dimesions:1200*1200*720
* Weight:500kg
* Display:LCD display English language touch screen
* Power:AC220/50Hz
* Fuction:Wire cutting, stripping a single-ended, double-ended stripping, single-head crimping, twisting single-ended line, single-ended tinning
* Wire size:AWG32#-AWG16#
* Speed:5500/h AWG32#-16#
* Cutting length:Max length 450mm
* Stripping length:0.1mm-10mm
* Tinning length:1mm-10mm (Changable)
* Twisting length:2mm-10mm (Changable)
* Available wire:Electronic wire, high temperature wire, etc.
* Twisting way:Digital Operation (motor drive mode)
* Detective function:Lack of wire, wire tie, pressure checking
* Air pressure:More than 6kg

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine Mold

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine Tinning

BJ-2000FT Fully Automactic Single Head Twisting Machine And Tinning Machine Samples

Payment & Delivery

We Provide

Service

Automatic Terminal Crimping Machine BJ-1.5TA

bojin — Fri, 14 Aug 2015 06:45:05 +0000

Operation Video

Specification:

* Model: BJ-1.5TA
* Power: AC220v/50/60hz
* Capacity: 3800/h
* Cutting length: 30-9999mm
* Cutting accuracy: 1mm+cutting lengthx0.2%
* Stripping length: A edge: 0.5-8mm, Bedge: 0.5-10mm
* Twisting length: 3-8mm
* Pressure: 1.5t
* Air pressure: 5-6kgf
* Size: 670wx840lx1200h
* Weight: 315kg

Product features:

* The device constitutes a major use of imported raw materials, to complete the cutting wire, stripping, crimping and other movements precise, simple operation, stable performance.
* Pressure line roller elastic torsional rotation using the fine-tuning adjustments quick and easy
* Cutting, stripping length adjustment using the touch screen. Best features: technical performance tuning fast adjustment time is short, simple and easy to operate

Automatic Terminal Crimping Machine BJ-1.5TA

Payment & Delivery

We Provide

Service

BJ-350 Full Automatic Terminal Crimping Machine

bojin — Thu, 23 Jan 2014 04:16:31 +0000

Operation Video

Feature

* The first machine researched & developed independently in China. Special designed for Automobile Harness.
* Modularized design, different functions can be attached: sealing, twisting, tinning wires.
* High-tech: the outstanding mechanic, electric and pneumatic integration.
* High-precision: servo-controlled module to realize the precise locating.
* Super-high speed: double closed loop length measurement module to realize the perfect integration of precision and speed.
* Independent intellectual property rights: independent R&D of the whole-machine, machinery and electric control. Additional functions are extensible.
* Ergonomic design: industrial control PC; providing an easy-to-understand man-machine interactive interface. The employee training period is largely shortened.

Specifications

* Model: BJ-350
* Cutting Length: 60-10000 mm
* Stripping Length: front end:0–15 mm (up to30mm); back end:0–15 mm
* Wire Range: AWG 14 — AWG 26
* Wire Feeding Speed: MAX.6m/s
* Crimping force: 2.0 Ton
* Power: AC380 V 50/60HZ 3 PHASES
* Air Source: 0.5-0.6 Mpa
* Air Consumption: 6.5m3/h
* Dimensions: 3400 mm X 1100 mm X 1190 mm
* Weight: Approx. 940 kg

Payment & Delivery

We Provide

Service

Model Number	BJ-601E	BJ-602E	BJ-603E	BJ-604E
Crimping range	0.5-16mm2	0.5-16mm²	0.5-50mm²	0.08-120mm²
Output	2.5T	1.8T	2.5T	2.5T
Voltage range	AC 220V	AC 220V	AC 220V	AC 220V
Weight	10kg	6kg	6kg	6.5kg

BJ-2000F Single-head Wire Stripping & Terminal Crimping Machine

bojin — Thu, 23 Jan 2014 04:15:42 +0000

Operation Video

Technical parameters

Type	?Automatic computer single head terminal crimping machine BJ-2000F
Power	?AC220V 50 / 60HZ ( single phase )
Function	?Wire cutting, both side stripping, single side stripping,?single side crimping.
Capacity	?4500 strip/h (within 300mm length)
Speed	?>3000pcs/hours
Wire Processing range	?AWG # 30 – AWG # 20
Wire Length	?35mm-8m
Cutting length	?28mm-9999mm. Replacing some parts can cut to 25mm(shortest)
?Cutting fine	?Change range:1mm+ below cutting length 0.1%)
?stripping length	?0.1mm-50mm
?Air pressure	?0.5Mpa(5kgf/cm) About 200NL/Min
?Detection device	?It will alarm downtime when appears lack of abnormal,?insufficient air pressure.
?Pressure capacity	?19600N(2T)
?Twisting length	?AWG # 20-AWG # 30 (4mm-8mm)
?Machine size	?80 * 80 * 170(mm)
?Machine weight	?About 130kg

Feature

* This machine is composed by Mitsubishi controller from Japan, high precision, stable performance.
* Using 256 colors color touch screen, full Chinese menu, PLC control.
* Terminal crimping use Japanese motor mute terminal machine. No noise, low fault..
* Equipment is mainly made of original imported parts, complete severing the wire, stripping, terminal crimping dynamic is precision, simple operation, stable performance.
* Wire pressing roller tightness adjustable, cutter depth adopt spinner rotation adjustment, simple and quick.
* Full stripping length directly set by the touch screen Chinese menu panel setting. The best characteristics: Technology operation performance adjustment fast, short adjusting time, simple operation.

Payment & Delivery

We Provide

Service

Related Terminal Crimping Machine

Model Number	BJ-601E	BJ-602E	BJ-603E	BJ-604E
Crimping range	0.5-16mm2	0.5-16mm²	0.5-50mm²	0.08-120mm²
Output	2.5T	1.8T	2.5T	2.5T
Voltage range	AC 220V	AC 220V	AC 220V	AC 220V
Weight	10kg	6kg	6kg	6.5kg

BJ-3000F Full-automatic Wire Strip & Terminal Crimp Machine

bojin — Thu, 23 Jan 2014 04:14:39 +0000

Technical parameters

Type	?Automatic computer single head terminal crimping machine BJ-3000F
Power	?AC220V 50 / 60HZ ( single phase )
Function	?Wire cutting, both side stripping, single side stripping,?single side crimping.
Capacity	?4500 strip/h (within 300mm length)
Speed	?>5000pcs/hours
Wire Processing range	?AWG # 30 – AWG # 20
Wire Length	?35mm-8m
Cutting length	?28mm-9999mm. Replacing some parts can cut to 25mm(shortest)
?Cutting fine	?Change range:1mm+ below cutting length 0.1%)
?stripping length	?0.1mm-10mm
?Air pressure	?0.5Mpa(5kgf/cm) About 200NL/Min
?Detection device	?It will alarm downtime when appears lack of abnormal,?insufficient air pressure.
?Pressure capacity	?19600N(2T)
?Twisting length	?AWG # 20-AWG # 30 (4mm-8mm)
?Machine size	?80 * 80 * 170(mm)
?Machine weight	?About 130kg

Feature

Payment & Delivery

We Provide

Service

Related Terminal Crimping Machine

Model Number	BJ-601E	BJ-602E	BJ-603E	BJ-604E
Crimping range	0.5-16mm2	0.5-16mm²	0.5-50mm²	0.08-120mm²
Output	2.5T	1.8T	2.5T	2.5T
Voltage range	AC 220V	AC 220V	AC 220V	AC 220V
Weight	10kg	6kg	6kg	6.5kg

BJ-4000F Double-head Terminal Crimp Machine

bojin — Thu, 23 Jan 2014 04:13:21 +0000

Operation Video

Function

wire selected length cutting, both ends stripping, crimping, cutting depth and stripping length automatic setting and both ends half stripping. Transmission by electric motor reduces press air consumption. Suitable choice for motor bicycle, household appliances wiring harness process industry.

Technical parameters

Type	?Automatic computer Double head terminal crimping machine BJ-4000F
Power	?AC220V 50 / 60HZ ( single phase )
Function	?Wire cutting, both side stripping, single side stripping,?single side crimping. Double side crimping
Capacity	?3500 strip/h (within 300mm length)
Wire Processing range	?AWG # 32 – AWG # 18
Cutting length	?30mm-9999mm. Replacing some parts can cut to 35mm(shortest)
Wire length	?35mm-8000mm
Cutting fine	?Change range:1mm+ below cutting length 0.1%)
?stripping length	?0.1mm-10mm
?Air pressure	?0.5Mpa(5kgf/cm) About 200NL/Min
Detection device	?It will alarm downtime when appears lack of abnormal,?insufficient air pressure.
?Pressure capacity	?1.25T
?Twisting length	?AWG # 20-AWG # 30 (4mm-8mm)
?Machine size	?670 W* 840L * 1500 H(mm)
?Machine weight	?About 350kg

Payment & Delivery

We Provide

Service

Related Terminal Crimping Machine

Model Number	BJ-601E	BJ-602E	BJ-603E	BJ-604E
Crimping range	0.5-16mm2	0.5-16mm²	0.5-50mm²	0.08-120mm²
Output	2.5T	1.8T	2.5T	2.5T
Voltage range	AC 220V	AC 220V	AC 220V	AC 220V
Weight	10kg	6kg	6kg	6.5kg
