Product Description
|
?Picture |
|
? |
||||
|
?Model |
B-02A（S） |
B-02B（S） |
B-02C（S） |
B-02D（S） |
B-905（S） |
|
|
?Power Rating |
150W |
180W |
200W |
280W |
180W |
|
|
?Section Acreage |
0.1 ~ 1.5mm2 |
0.1 ~ 2.5mm2 |
0.1 ~ 4mm2 |
0.1 ~ 6mm2 |
0.1 ~ 10mm2 |
|
|
?Wire Size |
AWG 15 ~ 28 |
AWG 11 ~ 28 |
AWG 8 ~ 28 |
AWG 10 ~ 30 |
AWG 16 ~ 32 |
|
|
Pipe diameter |
?φ1mm-φ5mm |
?φ1mm-φ5mm??? |
?φ1mm-φ5mm??? |
φ1mm-φ8mm???? |
φ1mm-φ11mm??? |
|
|
?Cutting Length |
5-9999mm |
5mm-40mm-9999mm |
5-6000mm |
|||
|
?Stripping Length |
Wire Head: 0-25mm???? Wire End:0-15mm |
? |
0.1 – 999mm |
|||
|
?Cutting Tolerance |
± (0.2 + 0.0002 × L) ????(L = actual |
± L × 0.2% |
amendable |
|||
|
?Net Weight |
21Kg |
23Kg |
--31Kg |
32Kg |
36Kg |
|
|
?Wire Sample |
|
|||||
???????
Operation Video
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us
