Features
* Air pressure: 1.5-2.5kg/cm2
* Rating: 10W
* Twising length: 5-60mm
* Twisting area: 0.1-2 mm2
* Power supply： 110/220V AC 50/60Hz
* Size: L340*W190*H170mm
* Weight is 18kg
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
]]>
Specification
* Model: BJ-BHT
* Power: AC 110V/220V/ 50/60Hz 300W
* Display Way: Digital Display (LCD Display)
* Fitting Wire Section Acreage: 0.1-4.5mm2( AWG12#-AWG32#)
* Guide Pipe Diameter (Wire DIA.): ￠10
* Stripping Length: Head: 0-50mm End: 0-50mm
* Cutting Length: 1-60000mm
* Middle-stripping: 16 places of stripping
* Knife Material: High-quality Tungsten Steel
* Fitting Wire Material: PVC Teflon Glass Wire, Silica gel wire
* Cutting Tolerance: ±(0.2+0.0002×L)mm (L=Cutting Length)
* Speed : L=100MM, 4000-10000pcs/h
* Adjusting Speed: 0 Slowest, 9 Fastest
* Measurement: 420mm×390mm×280mm
* Net Weight:35Kg
* Drive way: Four drives
Electric Flat Sheathed cable Stripper Machine BJ-BHT
Electric Flat Sheathed Cable Stripper Machine BJ-BHT
Electric Flat Sheathed Cable Stripper Machine BJ-BHT
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
Product features
*Axis design,while stranding! Greatly improve production efficiency
*LCD backlit display,modern mobile operating prin ciple. People out of the digital set operation cumbersome vertigo fatigue andother shortcomings;
*The motor shaft directly,without loss of drive torque,zero maintenance,brushless,electromang netic brakes,belts and other mechanical wear
*A sound industrial grade protection circuit design, the data that has been set with perfect data protection, and data can be permanently stored
*Different segments can set different winding direction,speed having positive and megative counting function,minimal noise,high speed constant torque;
*Start fast,high speed, direct braking at high speed,high efficiency.For tension to prevent starting 0-9 kinds of ad hoc methods to choose from a slow start when a thin line around the system, you can set different segments were different slow start mode;
*The system has finished winding production statistics, automatic segment feature also optionally woud dan;
*Scope : electronic wire, winding wire, braided isolated lines, computer lines
Specification
| Power source | AC 110/220 50/60HZ single phase |
| Motor | Stepless motor 100w |
| Can be twisted path | 32AWG-16AWG |
| Operational capacity | A variety of specifications of electronic wire twisted(braided) |
| Operation | Single-action pedal |
| Volume | 220w*240l*240h(mm) |
| Weight | 10kg |
Wire Twisting Machine Samples
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us
Product features
*Axis design,while stranding! Greatly improve production efficiency
*LCD backlit display,modern mobile operating prin ciple. People out of the digital set operation cumbersome vertigo fatigue andother shortcomings;
*The motor shaft directly,without loss of drive torque,zero maintenance,brushless,electromang netic brakes,belts and other mechanical wear
*A sound industrial grade protection circuit design, the data that has been set with perfect data protection, and data can be permanently stored
*Different segments can set different winding direction,speed having positive and megative counting function,minimal noise,high speed constant torque;
*Start fast,high speed, direct braking at high speed,high efficiency.For tension to prevent starting 0-9 kinds of ad hoc methods to choose from a slow start when a thin line around the system, you can set different segments were different slow start mode;
*The system has finished winding production statistics, automatic segment feature also optionally woud dan;
*Scope : electronic wire, winding wire, braided isolated lines, computer lines
Specification
| Power source | AC 110/220 50/60HZ single phase |
| Motor | Stepless motor 100w |
| Can be twisted path | 32AWG-16AWG |
| Operational capacity | A variety of specifications of electronic wire twisted(braided) |
| Operation | Single-action pedal |
| Volume | 220w*240l*240h(mm) |
| Weight | 10kg |
Wire Twisting Machine Samples
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us
Specification
* Model: BJ-02T
* Wire Gauge Range: AWG16 ~ AWG32
* Memory Function: Max. 99
* Power Supply: 220V / 50Hz
* Power Rating: 300W
* Display Way: LED Display
* Wire Size: AWG16-32
* Fitting Wire Section Acreage(Single Pipe): 0.1mm2-6.0mm2
* Fitting Wire Section Acreage(Double Pipe): 0.1mm2-2.5mm2
* Guide Pipe Diameter(Wire DIA.): Φ6mm (Double Pipe)
* Twisting length: Head: 0.1-30mm, Tail: 0.1-20mm
* Stripping Length: Head: 0.1-30mm, Tail: 0.1-20mm
* Cutting Length: 0.1-10m
* Cutting Tolerance: ±(0.002×L) (L=Cutting Length)
* Exhausted Line Way: Complete Half Brief Middle
* Processing Capacity: 15000pcs/hour
* Fitting Wire Material: PVC Teflon Glass Wire
* Drive Way: Four Wheel Drive At The Same Time
* Speed Adjustment: 1-9
* Wire Diameter Adjustment: Automation
* Twisting Way: Both sides or one side
* Max. Middle Stripping Section: 16
* Parameter Memory Function: Can save 99 kinds of different wires
* Blade Material: Hard tungsten steel
* Mearsurement: 500*520*360mm
* Net Weight: 42Kg
* Pacakage: Export standard package
Features:
* This machine can strip, cut and twist multi-core wire full automatically!
* Twiting two wires at the same time!
BJ-02T Wire Stripping & Twisting Machine
BJ-02T Wire Stripping & Twisting Machine
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
Related Wire stripping machines
| Model Number | BJ-02B | BJ-02D | BJ-02F | BJ-02MAX |
| Wire size | 0.1 – 2.5mm2 | 0.1 – 4.5mm2 | 0.2 – 8.0mm2 | 0.2 – 16mm2 |
| Conduit diameter | Φ6 | Φ6 | Φ10 | Φ13 |
| Wire Gauge Range | AWG16 – AWG32 | AWG12 – AWG32 | AWG8 – AWG32 | AWG5 – AWG30# |
| Drive Mode | Four-wheel drive | Four-wheel drive | Four-wheel drive | Four-wheel drive |
| Weight | 35kg | 35kg | 35kg | 35kg |
]]>
1. This machine should work together with computer wire stripping & cutting machine, this machine is used for twisting wires.
2. Two to five wires can be twisted at the same time.
3. Stripping length: 5-20mm
4. Wire size: AWG8-32
5. Power rating: 120W
6. Weight: 10kg
7.Measurement: 300*250*220mm
Operation Video:
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
Related Wire stripping machines
| Model Number | BJ-02B | BJ-02D | BJ-02F | BJ-02MAX |
| Wire size | 0.1~2.5 mm2 | 0.1- 4.5mm2 | 0.2 – 8.0 mm2 | 0.2– 16mm2 |
| Conduit diameter | Φ6 | Φ6 | Φ10 | Φ13 |
| Wire Gauge Range | AWG16 – AWG32 | AWG12 – AWG32 | AWG8 – AWG32 | AWG5-AWG30# |
| Drive Mode | Four-wheel drive | Four-wheel drive | Four-wheel drive | Four-wheel drive |
| Weight | 35kg | 35kg | 35kg | 35kg |
Usage
Worked by the micro-motor. The machine is small and easy to move, low voice, fast speed. Apply for the single-multi plastic and copper wire’s striping and twisting. Can strip and twist at the same time.
Performance and parameters
* Model: XC-180
* Input voltage: AC220V/50Hz
* power: 40W
* Weight: 6Kg
* Processing Range: 1-4mm
* Processing range: 0.1-1.5mm2
* Striping length: 2-20mm
* Specification: 210L×125W×155Hmm
Procedures of operation
a. first please set the length of the wire.
b. according to your line size, select the matched die approach, then you need adjust the length of the wire which needed twisting and striping.
c. start the machine.
d. setting the parameter machinery speed.
e. quickly put the wire into the die approach, and quickly pull out at the same time, and then it is finished.
XC-180 Wire Stripping & Twisting Machine
XC-180 Wire Stripping & Twisting Machine
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
Related Wire stripping machines
| Model Number | BJ-02B | BJ-02D | BJ-02F | BJ-02MAX |
| Wire size | 0.1~2.5 mm2 | 0.1- 4.5mm2 | 0.2 – 8.0 mm2 | 0.2– 16mm2 |
| Conduit diameter | Φ6 | Φ6 | Φ10 | Φ13 |
| Wire Gauge Range | AWG16 – AWG32 | AWG12 – AWG32 | AWG8 – AWG32 | AWG5-AWG30# |
| Drive Mode | Four-wheel drive | Four-wheel drive | Four-wheel drive | Four-wheel drive |
| Weight | 35kg | 35kg | 35kg | 35kg |
Specification
* Used for stripping and twisting wires
* Stripping length: 2-30mm
* Wire size: AWG14-22
* Power Rating: 120W
* Weight: 15kg
* Measurement: 300*200*160mm
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us.
Related Wire stripping machines
| Model Number | BJ-02B | BJ-02D | BJ-02F | BJ-02MAX |
| Wire size | 0.1~2.5 mm2 | 0.1- 4.5mm2 | 0.2 – 8.0 mm2 | 0.2– 16mm2 |
| Conduit diameter | Φ6 | Φ6 | Φ10 | Φ13 |
| Wire Gauge Range | AWG16 – AWG32 | AWG12 – AWG32 | AWG8 – AWG32 | AWG5-AWG30# |
| Drive Mode | Four-wheel drive | Four-wheel drive | Four-wheel drive | Four-wheel drive |
| Weight | 35kg | 35kg | 35kg | 35kg |
